ODOT-PNM02 V2.0 / V2.1: Modbus-RTU/ASCll Or Non-Standard Protocol To ProfiNet Converter
ODOT-PNM02 V2.1
Modbus （master/slave, RTU/ASCII) to ProfiNET, 2 port serial port (RS485/ RS232 / RS422), supports 50 slots, 200 commands in TIA
portal (by configured software), support MAX 60 slaves
♦ Supports protocol conversion between Modbus and PROFINET
♦ Supports 2* RS485/RS232 or 1*RS422
♦ Supports Modbus master or slave, and supports RTU or ASCII
♦ Supports working temperature of -40〜85°C
♦ Supports data area: 2 serial Modbus-RTU/ASCII to PROFIBUS gateway with Max. input 1440 bytesand Max. output 1440 bytes
♦ Supports one key reset
♦ ODOT-PNM02 V2.0 supports Maximum slots: 50
♦ ODOT-PNM02 V2.1 supports 60 slaves (200 read and write commands)
